11 Supplement
VEGAPULS 63 • Modbus and Levelmaster protocol
41364-EN-170711
11 Supplement
11.1 Technical data
Note for approved instruments
The technical data in the respective safety instructions are valid for approved instruments (e.g. with
Exapproval).Thesedatacandierfromthedatalistedherein,forexampleregardingtheprocess
conditions or the voltage supply.
General data
316L corresponds to 1.4404 or 1.4435
Materials, wetted parts
Ʋ Hygienic antenna encapsulation PTFE, TFM-PTFE, PFA
Ʋ Surface roughness of the antenna
encapsulation
R
a
< 0.8 µm
Ʋ Additional process seal with certain
hygienicttings
FKM, EPDM
Materials, non-wetted parts
Ʋ Processtting 316L
Ʋ Plastic housing plastic PBT (Polyester)
Ʋ Aluminium die-cast housing Aluminium die-casting AlSi10Mg, powder-coated (basis:
Polyester)
Ʋ Stainless steel housing 316L
Ʋ Cable gland PA, stainless steel, brass
Ʋ Sealing, cable gland NBR
Ʋ Blind plug, cable gland PA
Ʋ Seal between housing and housing lid Silicone SI 850 R, NBR silicone-free
Ʋ Inspection window in housing cover
(optional)
Polycarbonate
Ʋ Ground terminal 316L
Conductive connection
Betweengroundterminalandprocesstting
Processttings
Ʋ Flanges DIN from DN 25, ASME from 1"
Ʋ Hygienicttings Clamp, slotted nut according to DIN 11851, hygienic
ttingwithsaddleangeaccordingtoDIN11864-2-A,
SMS
Weight (depending on housing, process
ttingandantenna)
approx. 3.5 … 15.5 kg (4.409 … 33.95 lbs)
Torques
Requiredtorqueoftheangescrews 60 Nm (44.25 lbf ft)
Recommended torque for tightening the
angescrews
60 … 100 Nm (44.25 … 73.76 lbf ft)
Max. torque for NPT cable glands and Conduit tubes
Ʋ Plastic housing 10 Nm (7.376 lbf ft)
