11 Supplement
VEGAPULS 69 • Foundation Fieldbus
47251-EN-160815
Parameter list
The following table gives you an overview of the parameters used.
FF desciptor Description Unit
PRIMARY_VALUE
PRIMARY_VALUE(Linearizedvalue).Thisistheprocessval-
ueaftermin/maxadjustmentandLinearizationwiththestatus
ofthetransducerblock.Theunitisdenedin"PRIMARY_VAL-
UE_UNIT"
PRIMARY_VALUE_UNIT Selected unit code for "PRIMARY_VALUE"
SECONDARY_VALUE_1 This is the measured value after min/max adjustment with the
statusofthetransducerblock.Theunitisdenedin"SECOND-
ARY_VALUE_1_UNIT"
SECONDARY_VALUE_1_
UNIT
Selected unit code for "SECONDARY_VALUE_1"
SECONDARY_VALUE_2 This is the distance value ("sensor_value") with the status of the
transducerblock.Theunitisdenedin"SECONDARY_VAL-
UE_2_UNIT"
FILL_HEIGHT_VALUE
Fillingheight.Theunitisdenedin"FILL_HEIGHT_VALUE_
UNIT"
FILL_HEIGHT_VALUE_UNIT Filling height unit
CONST_VALUE Constant value
SECONDARY_VALUE_1_
TYPE
Secondary value 1 type
SECONDARY_VALUE_2_
TYPE
Secondary value 2 type
FILL_HEIGHT_VALUE_Type Filling height value type
DIAGNOSIS AITB Diagnosis
DIAG_MASK_1
DIAG_OUT_1
DIAG_MASK_2
DIAG_OUT_2
DEVICE_IDENTIFICATION Manufacturer ID, device type, bus type ID, measurement princi-
ple, serial number, DTM ID, device revision
DEVICE_NAME Device name
IS-SPARE_ELECTRONICS Device name
DEVICE_VERSION_INFO Hard- and software version for system, function and error
CALIBRATION_DATE Day, month and year
FIRMWARE_VERSION_ASCII Software version
HW_VERSION_ASCII Hardware version
ADJUSTMENT_DATA
Min./max.-adjustmentphysical,percentandoset
FIRMWARE_VERSION_MAIN Firmware versions major, minor, revision and build
PHYSICAL_VALUES Distance, distance unit, distance status, level and status
DEVICE_UNITS Distance and temperature units of the instrument
