11 Supplement
VEGAPULS 69 • Foundation Fieldbus
47251-EN-160815
FF desciptor Description Unit
APPLICATION_CONFIG Medium type, media, application type, vessel bottom, vessel
height
LINEARIZATION_TYPE_SEL
Typeoflinearization
SIMULATION_PHYSCAL
INTEGRATION_DATA
Physicalosetandintegrationtime
DEVICE_CONFIG_PULS_
RADAR
Electronics variant, probe type, max. measuring range, anten-
na extension length, adjustment propagation antenna extension
lprapprovalconguration
ADJUSTMENT_LIMITS_MIN Min.rangemin.-/max.-valuesphysical,percent,oset
ADJUSTMENT_LIMITS_MAX Max.rangemin.-/max.-valuesphysical,percent,oset %
FALSE_SIGNAL_COMMAND %
FALSE_SIGNAL_CMD_CRE-
ATE_EXTEND
FALSE_SIGNAL_CMD_DE-
LET_REGION
FALSE_SIGNAL_CMD_STATE Busy, last command, errorcode
FALSE_SIGNAL_CMD_CON-
FIGURATION1
Amplitude safety of the 0 % curve, safety of the false signal sup-
pression, position of the 0 % and 100 % curve in near and far
range
FALSE_SIGNAL_CMD_CON-
FIGURATION2
Gradient of the manual sectors, safety at the end of false echo
memory and depending on the import range gating out the false
signals
ECP_CURVE_AVARAGING_
CONFIG
Averaging factor on increasing and decreasing amplitude
LEVEL_ECHO_MEASURE-
MENT
Functionmeasuredvaluelter
ECHO_CURVE_STATUS
PACKET_COUNT
GU_ID_END
ECHO_CURVE_READ Echo curve data
ECHO_EVALUATOR
Echoparameters,rstlargeecho,amplitudethresholdrst
large echo
ECHO_DECIDER Echo selection criteria, fault signal on loss of echo, delay on
fault signal on loss of echo
DISPLAY_SETTINGS Indication value, menu language, lightning
SIL_MODE
EDENVELOPE_CURVE_FIL-
TER
Parametersofenvelopecurvelter,activationofsmoothraw
value curve
EDDETECTION_CURVE_FIL-
TER
Parametersofthedetectionlter,osetthresholdvaluecurve
EDECHO_COMBINATION Parameters for echo combination, function combine echoes,
amplitudedierenceofcombinedechoes,positiondierenceof
combined echoes
