THE front face of this reinforcement will be located in the station 31 , check
placement before gluing. Dig the core from the edges of this panel and pass a FLOX paste
in this cavity protruding from the edges, position the panel at the bottom of the fuselage
designated for it, place the FLOX paste on the joints to be glued (to form a small radius)
and glue the reinforcement with 2 layers of IDB on both sides of this panel.
