Electrical Component Testing

Fuses

Figure 41

G424902

Front fuse box

Power relay module

Rear fuse box

The electrical system is protected by fuses. It requires no maintenance, however, if a

fuse blows check the component/circuit for a malfunction or short.

Fuse Identification, Location, and Function

Front Fuse Panel Layout (Serial # 01001 — 02172)

G424761

4520Z Page 6–9 Electrical System: Electrical Component Testing

09.40001Rev 00
