Removing and Installing the Right Hydraulic Pump
Cover (continued)
6. Switch the main circuit breaker to the ON position, to energize the electrical
system.
Removing and Installing the Hydraulic Filter Access
Cover
Figure 82
G446042
Mounting bolt
Hydraulic filter access cover
1. Park the machine on a level surface, lower any attachments to the ground,
engage the parking brake, and remove the key from the ignition.
2. Switch the main circuit breaker to the O
FF position, to de-energize the electrical
system.
3. Remove the hydraulic filter access cover
, by removing the mounting bolts .
4. To install the hydraulic filter access cover, position the cover on the machine
aligning the mounting holes.
5. Install the mounting bolts.
6. Switch the main circuit breaker to the O
N position, to energize the electrical
system.
4520Z Page 7–17 Chassis: Service and Repairs
09.40001Rev 00
