Engine Cooling System
Figure 11
G419423
Radiator Assembly
Radiator Mounting Bolts
Air Inlet Cover
Air Box Mounting Bolt
Lower Radiator Hose
Upper Radiator Hose
4520Z Page 4–15 Engine: Engine Service and Repairs
09.40001Rev 00
