E: S2750e Series Technical Specifications
48 Verint Video Intelligence Solutions
Here are the S2750e series technical specifications:
Sensor/Lens Imaging device 1/3-inch Sony CCD
Picture elements 768 (H) x 494 (V) NTSC
752 (H) x 482 (V) PAL
Synchronization Internal
Iris control DC auto iris
Day/night support Automatic software function
Focal length 4 mm to 9 mm, 2.3x varifocal
Aperture ratio F1.6
Field of view 71°H x 51.6°V to 31.6°H x 23.6°V
Video Compression MPEG-4-based, MPEG-4 ISO 14496-2 compliant,
MJPEG
Frame rate Up to 30 frames per second programmable (full
motion)
Analog output 1 composite, 1 Vpp into 75 ohms with a female
2.5 mm connector
Horizontal resolution 480 TV lines typical
Minimum illumination 1.2 lux, F/1.6 (50 IRE) in color
0.7 lux, F/1.6 (40 IRE) in black and white
Signal-to-noise ratio 48 dB (AGC off)
Resolution Scalable from 176 x 128 to 704 x 480 pixels
Standard NTSC or PAL
Bandwidth Configurable between 9 and 6000 kbps
Network Interface Ethernet 10/100Base-T
Connector RJ-45 jack
Protocols Transport: RTP/IP, UDP/IP, TCP/IP, multicast IP
Others: DNS and DHCP client
Security SSL-based authentication
Power PoE PoE 802.3af class 3 device
