250 Firmware Version 5.4
4. Enter Implement Information
Press and enter implement Make and Model. Press to continue.
5. Select Implement Attachment Type
Use the drop-down list to select an implement attachment method. Press to continue.
6. Enter Distance Application Point Offset
Use to enter distance from hitch to application point (Front to Back). Press to continue.
7. Select Controller
Use the drop-down menu to select controller or press to add a controller. Press to
continue.
8. Select Controller Device and Device Type
Select DirectCommand from the Device drop-down menu. Select Granular Strip-Till Control from the
Device Type drop-down menu. Press to continue.
9. Enter Controller Name
Controller name defaults to Direct Strip Till. Press to accept, or press to enter a new
name if desired. Press to continue.
10. Enter Full Swath Width
Full Swath width defaults to a value of 30 ft. Use to enter the full swath width of the implement.
Press to continue.
11. Select Application Type from the Implement Wizard:Application Channels screen.
Press the Granular Application button.
12. Select Controller
Use the drop-down menu to select same controller as above. Press to continue.
13. Container Setup (Equipment Setup Wizard: Container screen)
Press the desired channel button in order to enable or disable the controller channel. A check mark will
appear in the box when the container is ready to be configured.
Note: Channel 1 is automatically assigned as a seeding channel and is intentionally unavailable for
user to edit. Proceed with configuration of containers for channels 2 and 3.
14. Assign Container Name
Container name defaults to “Bin 2, or 3”. Press to enter a new name if desired.
15. Assign Container Capacity
Use to enter the container capacity. Press to accept.
