TABLE OF CONTENTS
1 Important Safety Instructions 1
1.1 EMC 1
1.2 Installation 1
1.3 Maintenance 2
1.4 Recycling the Used Battery 3
1.5 Connection Warnings 3
1.6 Operation 5
1.7 Standards 6
2 Installation and Operation 7
2.1 Unpacking and Inspection 7
2.2 Wiring Terminal View 9
2.3 Single UPS Installation 12
2.3.1 MTP 10-15-20kVA from 3-3 Setting to 3-1 Setting 19
2.4 UPS Installation for Parallel System 22
2.5 Software Installation 25
2.6 Back feed Protection 26
2.7 Connecting and Disconnecting Internal Battery Terminals (MTP 20-40kVA) 26
3 Operations 29
3.1 Operation Mode 29
3.1.1 Standby mode 29
3.1.2 Line mode (AC mode) 30
3.1.3 Battery mode 30
3.1.4 Bypass mode 31
3.1.5 ECO mode 32
3.1.6 Shutdown mode 32
3.1.7 Maintenance bypass mode 33
3.2 Button Operation 33
3.3 Screen Description 33
3.3.1 Main screen 35
3.3.2 Control Screen 36
3.3.3 Measure Screen 41
3.3.4 Setting Screen 43
3.3.5 Information Screen 64
3.3.6 Data Log Screen 68
3.4 Single UPS Operation 68
3.5 Parallel Operation 73
3.6 Fault Code 75
3.7 Warning Code 75
Proprietary and Confidential ©2024 Vertiv Group Corp. i
Vertiv™ Liebert® MTP Online UPS User Manual 20-40-80kVA
