2 Installation and Operation
2.1 Unpacking and Inspection
Unpack the package and check the package contents. The shipping package should contain:
• One UPS
• One user manual
• One monitoring software CD
• One RS-232 cable
• One USB cable
• One parallel cable (only available for parallel model) (option)
• One shared current cable (only available for parallel model) (option)
NOTE: Before the installation, inspect the unit. Make sure that there is no physical damage to the unit. Do not turn on
the unit and notify the carrier and dealer immediately if there is any damage or missing parts and accessories. Keep
the original packaging for future use. It is recommended to keep each equipment and battery set in their original
packaging because they have been designed to provide maximum protection during transportation and storage.
1. Use a forklift to move the product to the installed area. See Figure 2.1 below . Make sure the bearing capacity of
the forklift is sufficient.
2. See Figure 2.2 on the next page to remove carton and foams.
Figure 2.1 Moving of the Unit to the Installed Area
