MODEL 10kVA 15kVA 20kVA 30kVA 40kVA 80kVA
CAPACITY* 20kVA / 20KW 40kVA / 40KW 80kVA / 80KW
Standard Model
Type 12V / 9 Ah 12V / 9 Ah
N/A
Numbers (16+16) pcs (16+16) pcs x 2 strings
Recharge Time 9 hours recover to 90% capacity
Charging Current (max) 1.0 A ± 10% (Recommended) 2.0 A ± 10% (Adjustable)
Charging Voltage +/-218VDC ± 1%
Physical
Standard Model
Dimension, D X W X H
(mm)
626 x 250 x 826 780 x 300 x 1000
N/A
Net Weight (kgs) 139/141 250/260
Environment
Operation Temperature 0 ~ 40°C (the battery life will down when > 25°C)
Operation Humidity <95 % and non-condensing
Operation Altitude** <1000 m**
Acoustic Noise Level Less than 62 dB at 1 Meter Less than 70 dB at 1 Meter
Less than 75 dB at 1
Meter
Management
Smart RS-232 or USB Supports Windows® 2000/2003/XP/Vista/2008/7/8/10, Linux, Unix, and MAC
Optional SNMP Power management from SNMP manager and web browser
* Derate capacity to 90% when the output voltage is adjusted to 208VAC.
** If the UPS is installed or used in a place where the altitude is above than 1000 m, the output power must be derated 1% per 100 m.
*** Product specifications are subject to change without further notice.
Table 6.1 Specifications (continued)
84 Proprietary and Confidential ©2024 Vertiv Group Corp. 6 Specifications
Vertiv™ Liebert® MTP Online UPS User Manual 20-40-80kVA
