15/20 K 30 K 40 K
W/O internal
battery
W internal
battery CSB
12150
W internal
battery CSB
12200
W/O internal
battery
W internal
battery CSB
12200
W/O internal
battery
W internal
battery CSB
12200
Dimensions, W x D x H, (mm)
W/O Packaging 600×1000×2000
W Packaging 722×1122×2170
Weight, (kg)
Unit 260 550 660 290 690 300 700
Shipping 290 580 690 320 720 330 730
Color Black-Gray (RAL 7021)
Table 8.2 Physical Specifications
NOTE: For units fitted with the integral distribution POD, add 6.2in. (157mm) to the unit depth and add 20 to 30lb (9
to13kg) to the unit weight.
NOTE: Run times shown are approximate. They are based on new, fully charged batteries at a temperature of 77 °F (25
°C) with 100% resistive UPS loading. Different loading will change the actual run times. Run times listed may vary by
±5% due to manufacturing variances of the batteries.
The Table 8.3 below shows the actual backup time, but the maximum value displayed on the LCD is 249.9.
15 kVA Models Load Level
Battery- string Qty. 100% 90% 80% 70% 60% 50% 40% 30% 20% 10%
15 kW 13.5 kW 12 kW 11.25 kW 9 kW 7.5 kW 6 kW 4.5 kW 3.75 kW 1.5 kW
1 17.5 20.5 25.5 30 35.5 44 57 78.5 126 278.5
2 41.5 47.5 58 66 77 94.5 122 170 267 577
3 71.5 80.5 98 111.5 130 159 204 279.5 429.5 895
Table 8.3 Battery Run Time in Minutes—(37.5 Ah)
20 kVA Models Load Level
Battery- string Qty. 100% 90% 80% 70% 60% 50% 40% 30% 20% 10%
20 kW 18 kW 16 kW 15 kW 12 kW 10 kW 8 kW 6 kW 5 kW 2 kW
1 11.5 13.5 16 19.5 25.5 31.5 41 57 90.5 204.5
2 28 32.5 38 45.5 58 69.5 88 122 193.5 428.5
3 51.5 58 66.5 77 98 117.5 148.5 204 317.5 672.5
