30 kVA Models Load Level
Battery- string Qty. 100% 90% 80% 70% 60% 50% 40% 30% 20% 10%
30 kW 27 kW 24 kW 22.5 kW 18 kW 15 kW 12 kW 9 kW 7.5 kW 3 kW
1 6 7 8.5 10.5 13 16.5 24.5 34 56 123.5
2 17 19.5 23 28 34.5 43.5 59.5 79 126 272.5
3 30 34.5 40 47.5 57 70 95 127.5 200 425.5
40 kVA Models Load Level
Battery- string Qty. 100% 90% 80% 70% 60% 50% 40% 30% 20% 10%
40 kW 36 kW 32 kW 30 kW 24 kW 20 kW 16 kW 12 kW 10 kW 4 kW
1 4 5 6 7 9 11.5 16 25.5 41 90.5
2 11.5 13.5 16 19.5 24.5 31 41.5 60.5 92.5 201.5
3 21 24.5 28.5 34 41.5 51.5 66.5 98 148.5 317.5
NOTE: Run times shown are approximate. They are based on new, fully charged batteries at a temperature of 77 °F (25
°C) with 100% resistive UPS loading. Different loading will change the actual run times. Run times listed may vary by
±5% due to manufacturing variances of the batteries.
The Table 8.4 below shows the actual backup time, but the maximum value displayed on the LCD is 249.9.
15 kVA Models Load Level
Battery- string Qty. 100% 90% 80% 70% 60% 50% 40% 30% 20% 10%
15 kW 13.5 kW 12 kW 11.25 kW 9 kW 7.5 kW 6 kW 4.5 kW 3.75 kW 1.5 kW
1 18 21 26.5 31 37.5 48.5 65.5 94.5 151 342
2 59.5 67.5 81 92 107.5 133 171.5 235.5 369 782.5
3 100.5 114 136.5 155.5 180.5 221 282 382.5 583 1203
Table 8.4 Battery Run Time in Minutes—(50 Ah)
20 kVA Models Load Level
Battery- string Qty. 100% 90% 80% 70% 60% 50% 40% 30% 20% 10%
20 kW 18 kW 16 kW 15 kW 12 kW 10 kW 8 kW 6 kW 5 kW 2 kW
1 13 15.5 18.5 22 29 36.5 48.5 70.5 113 257.5
2 41.5 47.5 55 64.5 81 96.5 123.5 171.5 269 584.5
3 71.5 80.5 93 109 136.5 162.5 206 282 433 906.5
