Alarm message
Description
Output phase
No. set
to 3
The output phase has been changed from 1-phase to 3-phase
UPS out of service
The UPS is out of service
Switch on
programmable output
The programmable output status has been changed from Switch Off to Switch On
Switch off
programmable output
The programmable output status has been changed from Switch On to Switch Off
System parallel
settings start sync
Set the 'Sync parallel parameters' command manually to activate the event
Local se
ttings sync
OK
The local parameters have been synchronized successfully
System settings sync
OK
All the parameters have been synchronized successfully
Load off due to output
short
There is a short circuit on the inverter or bypass output Carry out the appropriate checks
Output off due to
overload & bypass
abnormal
The output has been switched off due to an overload and the bypass supply is abnormal. Carry out
the
appropriate checks
Parallel No. abnormal
The
parallel
on
-
line
number
and
the
configured
val
ue
are
inconsistent
Please
check
that
the
parallel
number
on the 'Settings' page is the same as the actual on-line number, and that the parallel cables are normal
Bypass disabled
If
Settings
-
>Output
-
>Frequency
is
set
to
'Auto,
BypDisa;
50Hz,
BypDisa;
60Hz
,
BypDisa',
the
LCD
will
generate
the BypDisa alarm
In intelligent sleep
mode
When intelligent sleep mode is enabled, the system may perform N sets of inverter start
-
up.
Conditions for entering sleep mode:
- The UPS must be connected to a common, large battery string (if there is no large battery string,
entering sleep mode will result in the charger failing to recharge the battery),
- sleep mode must be enabled on the host,
- there must be no faults or alarms active on the inverter or rectifier,
- the battery must not require recharging,
-
a period of at least 1 hour must have elapsed since last exiting sleep mode,
- the unit is not the master unit
- with the exception of the module in sleep mode, the local unit ID number has not received a start-
up command within the last 5 minutes.
When the N minus 2 unit rated load is larger than the existing system rated load capacity, the unit with the
largest ID number starts to enter sleep mode (inverter off), at this point, N minus
1
units are operating in
inverter mode.
When the N minus 3 units are larger than the current system rated load capacity, the unit with the largest
ID
number remains in sleep mode
Battery cabinet
connection abnormal
The system detects that there are more than six battery
cabinets connected and i
ndicates that the battery
cabinet connection is abnormal
Battery cabinet not
connected
The battery cabinet group number is specified, but the communication cables are not connected
Battery EOD
Battery end of discharge
voltage reached
Faults cleared
Pres
s the 'Clear faults' button on the 'Control’ page, the system then records this event
Manual shut off
After the user shuts down the UPS output, the system will record this event
System warning
In the case of
parallel systems, this alarm is generated when
the UPS auto
-
adapting output frequency is
inconsistent. Solution: Switch on again
System fault
This alarm occurs when the model identification is incorrect. Solution: Contact service manager
If the alarm is generated as the result of a software value set-up by an authorised VERTIV engineer, and you wish to modify
the setting, please get in touch with your local VERTIV customer service centre.
