Electrical Specifications (Input Rectifier)
Table 10-4 Rectifier AC input (mains)
Item Unit
wire (+PE) TN/TT power distribution system
Power factor
(half load)
0.99 (0.98)
Total current ha
distortion
%
Linear full load < 3% (battery float charge) (3
Non-linear full load < 5% (battery float charge) (3-in 3-out)
Linear half load < 7% (battery float charge) (3-in 3-out)
Non-linear half load < 8% (battery float charge) (3-in 3-out)
1.
The rectifiers will operate at any of the rated supply voltages and frequencies without the need for any further adjustment.
2.
At 305V input mains, the UPS maintains the specified output voltage at rated load without discharging the battery.
10.5
Electrical Specifications (Intermediate DC Circuit)
Table 10-5 Battery
Item Unit
Rated power (kVA)
Float voltage
V/cell (VRLA)
2.27 (selectable from 2.2V/cell to 2.3V/cell)
Constant current and constant voltage charge mode
3.0 (selectable from 0 to
5.0 around 25°C or 30°C, or inhibit)
Boost voltage
V/cell (VRLA)
2.35 (selectable from 2.3 to 2.4)
Constant current and constant voltage charge mode
Boost control
boost current trigger 0.05C
10
Boost-float current trigger 0.02C
10
(selectable from 0.01 to 0.05)
12h safety time time-out (selectable from 5h to 24h)
Boost mode inhibit also selectable
Battery charger
V/cell
Constant current and constant voltage charge mode;
Boost charge mode automatic trigger or boost charge mode inhibit
also selectable
1.
When the number of battery is 24-block, the maximum output capacity of the UPS is 70% of rated capacity.
