Figure 6.45 Network setup unit—System/Network setup, page 2 of 2
Monitoring Protocol—Selects the monitoring protocol. Velocity V4 is the factory default that will provide
communications to the Liebert IntelliSlot housing. iGMNet will activate the 77/78 terminals for
communication to the Liebert SiteLink(-E). Hironet is used only on HPM units.
IP Address—Contains the network address of the display. This address must be unique on the network.
The factory default is 192.168.254.003.
Netmask—Defines which part of the IP address is used for the network. The factory default is
255.255.255.000.
Gateway—A network point that acts as an entrance to another network. The factory default is
0.000.000.000.
MAC—A unique hardware identifier of the Ethernet device.
The following parameters—U2U Protocol, U2U Address and U2U Group—are for displaying other
networked Liebert XDCs. The Liebert XDC does not perform Team Work operations.
U2U Protocol—Always set to GBP.
U2U Address—A unique identifier for each display on the network. Display addresses range
from 1 to 32. Each display on the U2U network must have a different U2U address. Not currently
used.
U2U Group—Used to create zones or groups within a U2U network. Once a group number is
selected, the display will see only other devices with the same group number. The group
number can be changed to view other devices in different groups. Not currently used.
Bootloader Variables—Indicates whether the bootloader has changed since it was last loaded. This
parameter should be activated only by an authorized service person.
Static RAM—Allows service personnel to clear and reboot the control board’s RAM. This should be
performed only by Vertiv or Liebert Service personnel.
