3 INSTALLATION
3.1 Mechanical Considerations
3.1.1 Positioning the Liebert XDC
Install the Liebert XDC according to the site specific documentation and secure the unit to the floor.
The Liebert XDC can be installed near a wall or another Liebert XDC. However, there must be at least
3feet(92cm) clearance in front of the Liebert XDC as service access for components in the unit.
NOTE: During installation of the Liebert XDC, the top, bottom, front and left side of the unit must be
accessible.
Figure 3.1 Dimensional data
Air-Cooled
Model
Dimensional Data, inches (mm)
Shipping Weight
lb. (kg)
50/60Hz A B* C D E F Domestic Export
XDC160 74 (1880) 34 (864) 33-1/8 (841) 33 (838) 72 (1829) 78 (1981) 1975 (896) 2109 (957)
*Dimension does not include the bezel of the disconnect switch, the handle or the control bezel.
Table 3.1
Liebert XDC dimensions, weight
Vertiv | Liebert® XDC™ User Manual | 15
