VESDA LaserPLUS - LaserPLUS Components

VESDA
®
LaserPLUS Product Guide
7
LaserPLUS Components
Figure 6 - An exploded view of the detector
A
B
C
D
E
F
G
H
Legend
A Front cover E Pipe inlet manifold
B Termination card F Air filter
C Blank card protecting processor card G Aspirator
D Chassis with laser detector chamber H Mounting box/enclosure
