1.4 LaserPLUS Product Information
Product Specifications
Supply Voltage 18 to 30 VDC
Power Consumption @24 VDC
• LaserPLUS with Blank
Plates 3,000rpm
Normal: 5.8 W
Alarm On: 6.24 W
• LaserPLUS with Blank
Plates @ 4,200rpm
Normal: 6.72 W
Alarm On: 7.2 W
• Programmer Module Normal: 1.08 W (Backlight Off)
Alarm On: 1.44 W (Backlight On)
• Display Module Normal: 1.6 W
Alarm On: 1.6 W
Dimensions (WHD) 350 mm x 225 mm x 125 mm (13.8 in x 8.9 in x 4.9 in)
Weight 4.0 kg (9 lbs) including Display and Programmer Modules
Operating Temperature
(To operate the LaserPLUS
detector outside these
parameters please contact
your nearest VESDA
Technical Office)
Detector Ambient:
UL tested: 0° to 39°C (32° F to 103°F)
Sampled Air: -20° to 60°C (-4° to 140°F)
Humidity: 10-95% RH, non-condensing
Storage Temperatures
(Non-operational)
Up to 2 years (battery life)
Dry (<95% humidity)
0° to 85°C
Must not exposed to sunlight or other radiation sources
Sampling Pipe Network Maximum length per pipe 100 m (328 ft)
Aggregate pipe length: 200 m (650 ft)
Pipe Modelling Design Tool: ASPIRE
2™
Pipe Size Internal Diameter: 15-21 mm (0.874 inch)
External Diameter: 25 mm (1.05 inch)
(25 mm to 1.050 inch adaptor supplied for USA market)
Relays 7 relays. Contacts rated 2A @ 30 VDC.
Programmable to latch or non-latch states
Programmable 0 - 60 seconds time delay for each relay
Relays Default Configuration 7 relays:
Alert, Action, Fire 1, Fire 2, Minor Fault, Urgent Fault and Isolate.
(7 x NO/NC contacts)
