Vespa LX 2012 User Manual

Capacities
CAPACITIES
Specification Desc./Quantity
Engine oil 1220 cm³ (of which 120 cm³ in the filtering cartridge)
Hub oil 200 cm³
Fuel tank capacity ~ 7 litres ± 0.5 litres
Electrical system
ELECTRICAL SYSTEM
Specification Desc./Quantity
Electric Electric starter
Ignition Electronic inductive discharge ignition, with variable advance
and separate HV coil.
Ignition advance Three-dimensional map managed by control unit
Spark plug NGK CR8EB
Electrode gap 0.7 to 0.8 mm
Frame and suspensions
FRAME AND SUSPENSION
Specification
Desc./Quantity
Chassis Stamped plate body with welded structural reinforcements.
Front suspension Single arm with helical spring and single double-acting hy-
draulic shock absorber.
Rear suspension Double-acting shock absorber, adjustable to four positions at
preloading.
Brakes
BRAKES
Specification
Desc./Quantity
Front brake Ø 200-mm disc brake with hydraulic control activated by han-
dlebar right-side lever.
Rear brake Ø 110-mm drum brake with mechanical control activated by
handlebar left-side lever.
Wheels and tyres
WHEELS AND TYRES
Specification
Desc./Quantity
Wheel rim type Light alloy wheel rims.
Front wheel rim 11'' x 2.50
Rear wheel rim 10'' x 3.00
Front tyre Tubeless, 110/70 - 11'' 45L
Rear tyre Tubeless, 120/70 - 10'' 54L
Front tyre pressure 1.6 bar
Rear tyre pressure (with passenger) 2.0 bar (2.3 bar)
Vespa LX - S 125 3V ie 150 3V ie (2012) Characteristics
CHAR - 11

Vespa LX 2012 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	124 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Transmission	Automatic CVT
Fuel Tank Capacity	8.6 liters
Seat Height	785 mm
Curb Weight	114 kg
Length	1, 770 mm
Width	705 mm
Height	1, 140 mm
Max Power	10.3 hp @ 7, 750 rpm
Front Suspension	Single arm with coil spring and hydraulic shock absorber
Front Brake	200 mm
Rear Suspension	Coil spring and hydraulic shock absorber
Rear Brake	110 mm drum
