Refitting
- Insert the components making sure to thoroughly
grease the O-ring and the fork oil seal.
- Follow the steps in reverse order taking care to
tighten to torque.
WARNING
IN ORDER TO PREVENT ABNORMAL FORMATIONS OF
DIRT DUE TO THE RELEASE OF GREASE, WE RECOM-
MEND FIRST LUBRICATING THE SEAL RING STOPS WITH
A BRUSH.
Locking torques (N*m)
Crankcase timing cover screws 11 to 13
Oil pump
Engine Vespa LX - S 125 3V ie 150 3V ie (2012)
ENG - 168
