- Insert the Seeger ring.
- Insert the alignment dowels if removed during
disassembly.
Removing the driven pulley
- Undo the clutch fixing screw, recovering the lin-
ing.
- Remove the clutch drum.
- Remove the driven pulley.
Engine Vespa LX - S 125 3V ie 150 3V ie (2012)
ENG - 118

Vespa LX 2012 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	124 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Transmission	Automatic CVT
Fuel Tank Capacity	8.6 liters
Seat Height	785 mm
Curb Weight	114 kg
Length	1, 770 mm
Width	705 mm
Height	1, 140 mm
Max Power	10.3 hp @ 7, 750 rpm
Front Suspension	Single arm with coil spring and hydraulic shock absorber
Front Brake	200 mm
Rear Suspension	Coil spring and hydraulic shock absorber
Rear Brake	110 mm drum
