This section describes the operations to be carried out on the engine and the tools to be used.
Automatic transmission
Transmission cover
- Remove the air duct.
- Remove the plastic cover that has the vehicle
logo on it.
- Insert the specific tools, rotate the engine until the
driven pulley stops and remove the nut, recovering
the washer.
Specific tooling
020937Y Driven pulley lock
Vespa LX - S 125 3V ie 150 3V ie (2012) Engine
ENG - 115

Vespa LX 2012 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	124 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Transmission	Automatic CVT
Fuel Tank Capacity	8.6 liters
Seat Height	785 mm
Curb Weight	114 kg
Length	1, 770 mm
Width	705 mm
Height	1, 140 mm
Max Power	10.3 hp @ 7, 750 rpm
Front Suspension	Single arm with coil spring and hydraulic shock absorber
Front Brake	200 mm
Rear Suspension	Coil spring and hydraulic shock absorber
Rear Brake	110 mm drum
