Vespa LX 2012 User Manual

Removing the driving pulley
- Using specific tools, lock the driving pulley and
loosen the nut.
Specific tooling
020938Y Driving pulley lock
- Remove the flat washer and the cup washer.
- Remove the stationary half-pulley and the wash-
er.
- Disengage the belt.
- Remove the complete roller housing.
Vespa LX - S 125 3V ie 150 3V ie (2012) Engine
ENG - 125

Vespa LX 2012 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	124 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Transmission	Automatic CVT
Fuel Tank Capacity	8.6 liters
Seat Height	785 mm
Curb Weight	114 kg
Length	1, 770 mm
Width	705 mm
Height	1, 140 mm
Max Power	10.3 hp @ 7, 750 rpm
Front Suspension	Single arm with coil spring and hydraulic shock absorber
Front Brake	200 mm
Rear Suspension	Coil spring and hydraulic shock absorber
Rear Brake	110 mm drum
