Maintenance chart
SCHEDULED MAINTENANCE TABLE
I: CHECK AND CLEAN, ADJUST, LUBRICATE OR REPLACE, IF NECESSARY C: CLEAN; R: REPLACE; A: ADJUST; L:
LUBRICATE
* Check level every 2,500 km
** Replace every 2 years
km x 1.000 or (months) maximum 1 (1) 5 (5) 10 (10) 15 (15) 20 (20) 25 (25)
Safety fasteners I I I
Spark plug I R I R I
Cartridge air filter C C
Centre stand bracket L L L L L
Driving belt (125 cm³) I R
Driving belt (150 cm³) R R
Throttle control A A A
Roller housing I I
Air filter I I
Engine oil filter R R R
Valve clearance A A A
Electrical system and battery I I I I I I
Cylinder ventilation system
Brake levers L L L
Brake fluid ** I I I I I I
Engine oil* R I R I R I
Hub oil I I
Headlight direction adjustment A A
Brake pads I I I I I I
Tyre pressure and wear I I I I I I
Vehicle road test I I I I I I
Odometer gear L L
Suspension I I
Steering A A A
Transmission L L
Labour time (minutes) 80 30 170 30 170 30
Spark plug
- Position the vehicle on the stand
- Remove the spark plug external inspection door
by undoing the indicated screw
Maintenance Vespa LX - S 125 3V ie 150 3V ie (2012)
MAIN - 38

Vespa LX 2012 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	124 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Transmission	Automatic CVT
Fuel Tank Capacity	8.6 liters
Seat Height	785 mm
Curb Weight	114 kg
Length	1, 770 mm
Width	705 mm
Height	1, 140 mm
Max Power	10.3 hp @ 7, 750 rpm
Front Suspension	Single arm with coil spring and hydraulic shock absorber
Front Brake	200 mm
Rear Suspension	Coil spring and hydraulic shock absorber
Rear Brake	110 mm drum
