Vespa LX 2012 User Manual

Sospensioni anteriore
This section is dedicated to operations that can be carried out on the suspensions.
Front
Removing the front wheel
- Support the vehicle adequately.
- Loosen the five screws fixing the wheel to the
hub.
Front wheel hub overhaul
- Support the vehicle adequately.
- Remove the front wheel.
- Remove the front brake calliper.
- Remove the cotter pin and remove the cap.
- Unscrew the nut fixing the front wheel hub.
Vespa LX - S 125 3V ie 150 3V ie (2012) Suspensions
SUSP - 207

Vespa LX 2012 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	124 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Transmission	Automatic CVT
Fuel Tank Capacity	8.6 liters
Seat Height	785 mm
Curb Weight	114 kg
Length	1, 770 mm
Width	705 mm
Height	1, 140 mm
Max Power	10.3 hp @ 7, 750 rpm
Front Suspension	Single arm with coil spring and hydraulic shock absorber
Front Brake	200 mm
Rear Suspension	Coil spring and hydraulic shock absorber
Rear Brake	110 mm drum
