Vespa LX 2012 User Manual

Inspecting the clutch spring
- Measure the length of the spring when it is re-
laxed.
Characteristic
Standard length:
106 mm
Refitting the driven pulley
- Reassemble the clutch housing and spacer.
Drive-belt
- Make sure the drive belt is not damaged and does not show abnormal wear.
- Replace as indicated in the scheduled maintenance table.
Engine Vespa LX - S 125 3V ie 150 3V ie (2012)
ENG - 124

Vespa LX 2012 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	124 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Transmission	Automatic CVT
Fuel Tank Capacity	8.6 liters
Seat Height	785 mm
Curb Weight	114 kg
Length	1, 770 mm
Width	705 mm
Height	1, 140 mm
Max Power	10.3 hp @ 7, 750 rpm
Front Suspension	Single arm with coil spring and hydraulic shock absorber
Front Brake	200 mm
Rear Suspension	Coil spring and hydraulic shock absorber
Rear Brake	110 mm drum
