Vespa LX 2012 User Manual

KEY
1. Instrument panel
9. Headlight relay
11. Fuses No. 3, 4, 6;
14. Fuse No. 2
15. Ignition switch
17. Starter remote control switch
18. Fuse No. 1
21. Battery
23. Injection load relay
26. Lambda probe
27. Engine speed sensor
28. H.V. coil
29. Diagnostics socket
30. Injector
31. Engine temperature sensor
32. Fuel pump
33. Side stand switch
34. Electronic control unit
Injection Vespa LX - S 125 3V ie 150 3V ie (2012)
INJEC - 182

Vespa LX 2012 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	124 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Transmission	Automatic CVT
Fuel Tank Capacity	8.6 liters
Seat Height	785 mm
Curb Weight	114 kg
Length	1, 770 mm
Width	705 mm
Height	1, 140 mm
Max Power	10.3 hp @ 7, 750 rpm
Front Suspension	Single arm with coil spring and hydraulic shock absorber
Front Brake	200 mm
Rear Suspension	Coil spring and hydraulic shock absorber
Rear Brake	110 mm drum
