Vespa LX 2012 User Manual

- Unscrew the nut fixing the wheel axle and collect
the washer.
Refitting the rear wheel
- To refit, follow the removal steps but in reverse
order; be careful to tighten to the prescribed tor-
que.
Locking torques (N*m)
Locking torque 137 to 152 Nm
Swing-arm
Vespa LX - S 125 3V ie 150 3V ie (2012) Suspensions
SUSP - 221

Vespa LX 2012 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	124 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Transmission	Automatic CVT
Fuel Tank Capacity	8.6 liters
Seat Height	785 mm
Curb Weight	114 kg
Length	1, 770 mm
Width	705 mm
Height	1, 140 mm
Max Power	10.3 hp @ 7, 750 rpm
Front Suspension	Single arm with coil spring and hydraulic shock absorber
Front Brake	200 mm
Rear Suspension	Coil spring and hydraulic shock absorber
Rear Brake	110 mm drum
