Removal
- Remove the front wheel
- Remove the front brake calliper
- Remove the hub and the disc operating on the
wheel axle nut
- Adequately support the hub with the disc and op-
erating on the five screws shown in the photo-
graph, remove the brake disc
Refitting
- Carry out the operations in the reverse order from
the removal being careful to respect the direction
of disc rotation shown by the arrow printed on it
- Tighten the 5 screws to the specified torque
Locking torques (N*m)
Brake disc screws: 6 +0.5 -1 Nm
Braking system Vespa LX - S 125 3V ie 150 3V ie (2012)
BRAK SYS - 230

Vespa LX 2012 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	124 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Transmission	Automatic CVT
Fuel Tank Capacity	8.6 liters
Seat Height	785 mm
Curb Weight	114 kg
Length	1, 770 mm
Width	705 mm
Height	1, 140 mm
Max Power	10.3 hp @ 7, 750 rpm
Front Suspension	Single arm with coil spring and hydraulic shock absorber
Front Brake	200 mm
Rear Suspension	Coil spring and hydraulic shock absorber
Rear Brake	110 mm drum
