Vespa LX 2012 User Manual

evenly. A 0.5 mm thickness difference in the re-
sidual friction material is permitted
Refitting
- Insert the brake pads
- Insert the fixing pin being careful to position the
clip with the ends towards the bleed screw as in
the photo.
- Insert the lock on the bolt and then the protection
cover
- Fix the brake calliper to the bracket and tighten
the two screws to the specified torque.
CAUTION
BEFORE USING THE BRAKE, OPERATE THE LEVER A
FEW TIMES.
Locking torques (N*m)
Rear brake calliper tightening screw 20 to 25 Nm
Fill
Braking system Vespa LX - S 125 3V ie 150 3V ie (2012)
BRAK SYS - 232

Vespa LX 2012 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	124 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Transmission	Automatic CVT
Fuel Tank Capacity	8.6 liters
Seat Height	785 mm
Curb Weight	114 kg
Length	1, 770 mm
Width	705 mm
Height	1, 140 mm
Max Power	10.3 hp @ 7, 750 rpm
Front Suspension	Single arm with coil spring and hydraulic shock absorber
Front Brake	200 mm
Rear Suspension	Coil spring and hydraulic shock absorber
Rear Brake	110 mm drum
