Vespa LX 2012 User Manual

Electrode gap
0.7 to 0.8 mm
Spark plug
NGK CR8EB
Locking torques (N*m)
Spark plug tightening 10 to 12
Hub oil
Check
- Park the vehicle on level ground and centre
stand.
- Undo the screw indicated:
•
oil comes out of the screw hole: the oil
quantity in the hub is adequate; place
it and tighten the screw.
•
oil does NOT come out of the screw
hole: the oil quantity in the hub, IS NOT
adequate and it is necessary to carry
out the top-up.
- With a cloth carefully clean the transmission
crankcase.
Replacement
- Remove the oil level check and filler screw.
Maintenance Vespa LX - S 125 3V ie 150 3V ie (2012)
MAIN - 40

Vespa LX 2012 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	124 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Transmission	Automatic CVT
Fuel Tank Capacity	8.6 liters
Seat Height	785 mm
Curb Weight	114 kg
Length	1, 770 mm
Width	705 mm
Height	1, 140 mm
Max Power	10.3 hp @ 7, 750 rpm
Front Suspension	Single arm with coil spring and hydraulic shock absorber
Front Brake	200 mm
Rear Suspension	Coil spring and hydraulic shock absorber
Rear Brake	110 mm drum
