Vespa LX 2012 User Manual

Level check
Proceed as follows:
- Rest the vehicle on its centre stand with the han-
dlebars perfectly horizontal;
- Check the level of liquid with the related warning
light «A».
A certain lowering of the level is caused by wear
on the brake pads.
Top-up
Proceed as follows:
- Remove the front handlebar cover.
- Remove the reservoir cap by loosening the two
screws, remove the gasket and top-up using only
the fluid specified without exceeding the maximum
level.
CAUTION
ONLY USE DOT 4-CLASSIFIED BRAKE FLUID.
CAUTION
AVOID CONTACT OF THE BRAKE FLUID WITH YOUR
EYES, SKIN, AND CLOTHING. IN CASE OF ACCIDENTAL
CONTACT, WASH WITH WATER.
CAUTION
BRAKING CIRCUIT FLUID IS HIGHLY CORROSIVE; DO
NOT LET IT COME INTO CONTACT WITH PAINTED PARTS.
CAUTION
BRAKE FLUID IS HYGROSCOPIC; THAT IS, IT ABSORBS
MOISTURE FROM THE SURROUNDING AIR. IF THE CON-
TENT OF MOISTURE IN THE BRAKE FLUID EXCEEDS A
CERTAIN VALUE, BRAKING WILL BE INEFFICIENT.
NEVER USE BRAKE FLUID FROM OPEN OR PARTIALLY
USED CONTAINERS.
UNDER NORMAL CLIMATIC CONDITIONS, REPLACE FLU-
ID AS INDICATED IN THE SCHEDULED MAINTENANCE
TABLE.
N.B.
SEE THE BRAKING SYSTEM CHAPTER WITH REGARD TO
THE CHANGING OF BRAKE FLUID AND THE BLEEDING
OF AIR FROM THE CIRCUITS.
Recommended products
AGIP BRAKE 4 Brake fluid.
Synthetic fluid SAE J 1703 -FMVSS 116 - DOT 3/4
- ISO 4925 - CUNA NC 956 DOT 4
Maintenance Vespa LX - S 125 3V ie 150 3V ie (2012)
MAIN - 46

Vespa LX 2012 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	124 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Transmission	Automatic CVT
Fuel Tank Capacity	8.6 liters
Seat Height	785 mm
Curb Weight	114 kg
Length	1, 770 mm
Width	705 mm
Height	1, 140 mm
Max Power	10.3 hp @ 7, 750 rpm
Front Suspension	Single arm with coil spring and hydraulic shock absorber
Front Brake	200 mm
Rear Suspension	Coil spring and hydraulic shock absorber
Rear Brake	110 mm drum
