f - Check the ignition of the green LED indicated
with a red arrow in figure.
g - The activation cycle of the new battery lasts for
30 minutes after the ignition of the recharge LED
has taken place
h - Disconnect the clamps from the battery and
check the voltage, if voltages are detected of less
than 12.8 V, proceed with a new recharge of the
battery starting from point c of the recharge pro-
cedure of the new battery, otherwise go to point i
i - The battery is now completely activated, disconnect the battery charger from the fuel supply grid,
disconnect the clamps from the battery and proceed to fitting the battery on the vehicle.
Vespa LX - S 125 3V ie 150 3V ie (2012) Electrical system
ELE SYS - 97

Vespa LX 2012 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	124 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Transmission	Automatic CVT
Fuel Tank Capacity	8.6 liters
Seat Height	785 mm
Curb Weight	114 kg
Length	1, 770 mm
Width	705 mm
Height	1, 140 mm
Max Power	10.3 hp @ 7, 750 rpm
Front Suspension	Single arm with coil spring and hydraulic shock absorber
Front Brake	200 mm
Rear Suspension	Coil spring and hydraulic shock absorber
Rear Brake	110 mm drum
