Vespa LX Series User Manual

Removing the butterfly valve
- Remove the helmet compartment.
- Remove the fuel piping clamping screw indicated
in the figure.
- Remove the fast-release fitting from the injector.
- Remove the injector connector.
- Remove the three screws with anti-tampering
device fixing the manifold to the head and the clip
fixing the throttle body to the manifold.
Remove the MIU ECU connector.
- Remove the fastening clamp of the air cleaner
joint to the air filter body.
Vespa LX 125 - 150 i.e. Injection
INJEC - 159
