- Working on the right side, unscrew the side fixing
nut to the chassis and collect the washer.
- Working on the left side, remove the pin.
- Remove the spoiler terminal from both sides.
- Working on the right side, unscrew the fixing nut.
- Working on the left side, release the pin from the
spring shown.
Vespa LX 125 - 150 i.e. Suspensions
SUSP - 201
