- Remove the fixing pin to the engine and collect
the spacer.
- Now the swinging arm is free.
- Remove the swinging arm from the vehicle; first
release it from the engine side and then from the
chassis side.
Overhaul
- Check that the silent-blocks are in good condi-
tions.
- Otherwise, replace the swinging arm.
Suspensions Vespa LX 125 - 150 i.e.
SUSP - 202
