Vespa LX Series User Manual

Battery recharge and starting
1. Magneto flywheel
2. Voltage regulator
3. 12V-10Ah Battery
4. Start-up remote control switch
5. Starter motor
6. Starter button
7. 20A Fuse
8. 7.5A Fuse
9. Stop light bulb
10. Key switch contacts
12. Stop buttons
15. Fuse 15A
26. Fuse 10A
28. Injection electronic control unit
Electrical system Vespa LX 125 - 150 i.e.
ELE SYS - 62

Vespa LX Series Specifications

General

Displacement	124 cc
Cooling System	Air-cooled
Front Tire	110/70 - 11"
Rear Tire	120/70 - 10"
Seat Height	785 mm
Kerb Weight	114 kg
Wheelbase	1, 280 mm
Length	1, 770 mm
Width	705 mm
Height	1, 140 mm
Engine Type	Single-cylinder, 4-stroke
Fuel System	Carburetor
Max Torque	10.4 Nm @ 6, 000 rpm
Transmission	Automatic
Front Suspension	Single-sided trailing arm with hydraulic shock absorber
Rear Suspension	Hydraulic shock absorber
Front Brake	200mm disc brake
Rear Brake	110mm drum brake
