Vicon Extra 124 - Cutting Disc Bolt and Guard

Maintenance
78
 Apply Loctite 242 or a similar product to all bolts.
 Fit the cutting disc on the cutterbar.
 Use a torque wrench to tighten the bolts to the torque shown.
 Close the guards around the machine's cutterbar.
 Fit the pin.
Loctite
242
Loctite 242
Bolt
80 Nm +/- 5
(59 ft. lbs. +/- 4)
Pin
