Assembly - attachment
27
> Mount the machine onto the tractor's lift arms.
Selecting the position of the top link:
T
IP
!
It is recommended that the top link is parallel to the tractor's lift arms.
> Connect the hydraulic hoses to the tractor's hydraulic outlet.
NB
It is recommended that the hydraulic outlet on the tractor is in the
floating position.
> Activate the tractor's lift arms and lift the hitch up completely.
> Turn the support leg around and raise it up as shown.
