28
Assembly - attachment
> Turn the catch to the position shown.
NB
The catch must be able to be turned to the position shown when the
machine is attached and is lifted free of the ground with the tractor's
three-point hitch.
> Attach the PTO shaft to the tractor.
• The freewheel on the PTO shaft should turn towards the machine.
NB
When checking and shortening the PTO shaft, refer to the
manufacturer's instructions, delivered with the PTO shaft.
> Lower the machine back down to the ground.
> Adjust the top link to the desired stubble height.
• Making the top link shorter reduces the stubble height
• Making the top link longer increases the stubble height.
»Stubble height« page 39
