Assembly - attachment
29
Adjusting the
working height
The suspension is adjusted in the following way:
> Raise/lower the lift arms until there is approx. 15 - 30 mm (
5
/
8
” - 1
3
/
16
”) clearance between the lock catch and the stop.
> Tighten the tractor's stabiliser chains.
Because of the increase in weight, it is recommended that the tractor's
left-hand stabiliser chain be tightened more than usual, so that the
machine is pulled as far to the left as possible.
15 - 30 mm (
5
/8”-1
3
/16”)
Lock catch
Stop
