Victoria Arduino BLACK EAGLE VA388 User Manual

SERVICE MANUAL
8.1
Edition 01 of 08/2017
8. ELECTRIC COMPONENTS
TOOLS NEEDED:
INDEX
8. ELECTRIC COMPONENTS . . . . . . . . 8.1
8.1 CONTROL UNIT .....................8.2
8.2 THE CONTACTOR ...................8.
6
8.3 STATIC RELAYS .....................8.
7
8.4 ACCESS TO THE STATIC RELAYS
AND THE SENSOR CARD ...........8.10
8.5 ACCESS AND
REPLACEMENT OF THE DIGITAL
PRESSURE GAUGE .................8.11
8.6
REPLACEMENT OF TFT SCREEN ....8.12
8.7 UPDATING THE TFT SCREEN ........8.14
8.8
REPLACEMENT OF GROUP PUSH
BUTTON PANELS AND SCREENS....8.16
8.9 MACHINE CONFIGURATION .........8.18
8.10 GRAVIMETRIC
CONTROL UNIT ....................8.19
8.11
LOAD CELLS AND SENSORS
(version G only) . . . . . . . . . . . . . . . . . . . . . 8.20
8.12 REMOTE CONTROL ................8.23
19 MM
8

Victoria Arduino BLACK EAGLE VA388 Specifications

General

Brand	Victoria Arduino
Model	BLACK EAGLE VA388
Category	Coffee Maker
Language	English
