3 Unscrew the hex screws to completely
remove the gravimetric unit.
8.11 LOAD CELLS AND SENSORS
(version G only)
The load cells allow the calculation of the actual
weight of the coffee dispensed from each group
and are positioned in the front area of the
machine.
To gain access the load cells:
1 Remove the front panel and the upper pan-
els.
2
Unhook drainage tube from its seat.
Edition 01 of 08/2017
8.20
SERVICE MANUAL
Fig. 316
Fig. 319
Fig. 318
Fig. 317
