COLD WATER VALVE
The same procedure also applies for the cold
water valve. In this case, since it is connected
with a tap it may be necessary to replace the
whole part.
WHEN TO INTERVENE
Problems related to the steam nozzle are:
t $POUJOVPVTMPTTPGTUFBN
t 8BUFSESJQQJOHGSPNUIFTUFBNOP[[MF
t %FMBZFEDMPTVSF
t 4UFBNMFWFSUPPMPPTF
DANGER
Before proceeding with the operations
described in the chapter make sure that the
machine is turned off and unplugged from the
mains. Discharge any residual pressure pre-
sent in the steam heater.
DANGER
Fig. 241
7.9 STEAM NOZZLE
The steam nozzle is composed of a piston actu-
ated by the knob, which presses on a nut with
spring return. By pressing against the spring it
creates space for the steam to pass.
We suggest to replace the seals that keep the
piston perfectly aligned, every 4-6 months. Every
year it is advisable to replace the nut to prevent
the gasket that insulates the steam from drying
BOE MFUUJOH TFBN QBTT 4JODF UIFTF QBSUT NVTU
be changed, we suggest replacing all the seals
simultaneously.
Edition 01 of 08/2017
7.19
SERVICE MANUAL
Fig. 239
Fig. 240
