Carefully remove the upper and lower covers.
2 Unscrew the pair of screws shown in the
figure using a Phillips screwdriver.
3 Remove the two screws that hold the front
parts of the cover and extract.
If there is a loss of vapour or condensation, it is
necessary to:
1 Turn the machine off, let out all the steam
until there is no pressure in the heater.
Edition 01 of 08/2017
7.20
SERVICE MANUAL
Fig. 243
Fig. 244
Fig. 245
Fig. 242
