HOW TO REPLACE THE HEATING ELE-
MENTS
To remove the heating elements cartridge initially
remove the screw that holds it in place with a
Phillips screwdriver.
The screw is located in the rear wall of the wall
that holds the unit. It is then necessary to remove
the corresponding cup warming modules before-
hand.
If the cartridge does not come out easily because
dilated by the temperature it can be forced out.
Remove the covers by the unit in question (see
corresponding paragraph), move the insulation
and push down into the hole in the bottom left to
easily remove the cartridge.
Pull out the cartridge and replace it if necessary.
Edition 01 of 08/2017
4.7
SERVICE MANUAL
Fig. 99
Fig. 100
Fig. 101
