Victoria Arduino BLACK EAGLE VA388 User Manual

5 Disconnect the motor.
6 Carefully remove the motor.
7 Remove the capacitor using a 13 mm wrench.
4 Unscrew the four screws holding the motor.
In the picture the holders that support the
motor plate.
Fig. 198
Edition 01 of 08/2017
7.7
SERVICE MANUAL
Fig. 199
Fig. 200
Fig. 201
