Victoria Arduino BLACK EAGLE VA388

SERVICE MANUAL
1.3
Edition 01 of 08/2017
1.2 KEYBOARD DESCRIPTION (Standard configuration)
Fig. 2
Machine On/
Off button
Cleaning
button
USB port
Cup warmer
On/Off
button
Rotary
switch
TFT display Display group
Coffee dispensing
buttons
